CALEFFI Safety Relief Valve Female With Pressure Gauge 6Bar Brass ½"

Features:

• Used in domestic hot water systems to protect the hot water cylinder and in heating systems to protect boiler and other components.
• The valve is selected for the required set pressure.
• As the pressure rises, when the discharge pressure is reached the valve opens and discharges to atmosphere, preventing the pressure within the system reaching levels which would be dangerous for the boiler, hot water storage cylinder and any personnel in the adjacent vicinity.

Technical data:

• Material - Brass
• Set pressure - 6Bar
• Discharge pressure - 7.2Bar
• Re-seating pressure - 4.8Bar
• Discharge flowrate - 248.8kg/hr
• Max boiling rating - 144.6kW
• WRAS Approved - Yes
• Brand - Caleffi

Product Code: 313460
